MHI H-Series Horizontal Tube Furnace
- Continuous use temperatures up to 1760C.
- Working Chamber Size 2.5″ID x 2.75″ OD x 12″L (wall-to-wall)
- MHI Molybdenum disilicide heating elements.
- Standard UL rated temperature controller, one program and 16 segments.
- Full furnace electronics included: MHI BPAN-O-Plus TM
- Furnace Power 6.8kW (No load state power, ~3.3kW).
- Customer must specify wiring requirements. 240V Standard
- FiberFree refractory
- Stainless Steel Construction
- Double Walled
- LED intensity lamps for control unit
- Decoupled power controller. Easy to fit in small spaces.
- Packing meets all international standards
Includes MHI BPAN-O-Plus TM Control Panel Details
- BPAN-O-PlusTM models have a UL microprocessor (PID) programmable controller (please note MHI also supplies cUL)
- Over temperature feature and independent display
- Best soft start and current limit included
- Durable enclosure (weight is approx. 7.3 kg)
- Digital communications RS232/485 220V models
- SCR power controller with current limiter (extended soft start included if required for heating device)
Includes Transformer to match device voltage from line voltage
Please contact MHI at 513-772-0404 or by email at [email protected] if you have any questions or need more information. Written price quote required from MHI.
