MRCL GA3125 Robust Radiator 1300°C with Control Panel and Transformer Options

MRCL-GA2125-6  (A=4″, B=6″, C=3″, D~7″, Lu=[D/2]+1.5) – for options, please choose them from the pull-down menu.

Chamber temperature estimate is 1200C to 1300C with end caps (CEC) for no flow applications (lower in flow applications).  Element temperature will not exceed 1400C in this model.

Maximum Power: ~2000 W.

Tube  diameter OD will be approximately 2.5″.

Choose metallic tube if applications is for gas flow.  Pressure not to exceed one atmosphere.  Gas temperature unlikely to exceed between 1o00C – 1100C. at full power.  Please choose enhancer tube option for maximum residence time.  Note tube will protrude out of RR ends.

Choose Ceramic tube if for heating object placed in tube

Robust Radiator™ is enclosed in a FiberFree™ ceramic refractory, which can withstand 1850°C temperature.

GAXP® element with a maximum temperature of 1400°C.

MagnaCoil Included.  Electronics (Control Panel and Control Transformer) are highly recommended.

With optional CEC and no internal tube or end-caps, the Robust Radiator™ is rated up to 1300°C.

With metallic tube and/or gas flow, the RR is rated at ~1100°C for the tube temperature.  Temperature indicates at T/C location in the RR.  This is outside the tube.

Hole for T/C provided.  TCs are included when the BPAN-O-PLUS is purchased.

OPTIONS:

• Electrical connectors – braided wire and clips
• BPAN-O-PLUS Control Panel
• Transformer to match device voltage
• Tube with and without residence time enhancers

For multiple RRs placed in series, please contact MHI for the control panels and temperature/power management.

If using combustible gas please ensure that the control panel is located in a explosion proof room.  Please note that the connectors are not rated for explosive gas.  It is the user responsibility to ensure leak proof gas connections and safety systems applicable for hazardous gas use.

Robust Radiator™ Section View with Dimensions

A= Heated Length
B= Overall Length
C= ID
D= OD
