GRR2(4)-220 – (End Connectors Included)

$3,895.00

  • Model: GRR2(4)-220
  • Manufacturer: Micropyretics Heaters International

Selected Options:

RHUL/GRR Outside SS shell *

Control Panels:

Thermocouple *

CEC (end plugs)- Type C for flow

Tube with sealed end caps. Tube rated to 1200C:

Please review our Terms and Conditions.

SKU: GRR2(4)-220 Categories: Radiative Heat Products, Robust Radiator
  • Description
  • Specifications

Description

GRR Robust Radiator Diameter 2″  Length 4″. This is the coil length and ID. At least 0.5″ extension on each side beyond coil length. Power 2.5 KW@ 240 Volts plug-in.

• Optional Tube with two end caps may be placed in the Robust Radiator. The tube will be mullite, and the end caps will be metal.
• Tube will protrude at least 1″ beyond the RR face. The tube is optional – supplied with end caps. Note ceramic plugs to limit heat loss (option CEC) but with the ability to maintain flow are also offered as options. These are recommended.

• Please note that the power available from the RR for heating is lower when a tube is placed in it
• The internal temperature in the tube will depend on the load in the tube
(Picture shows optional tube and SS shell). These have to be purchased in the pull-down menu.

The GRR will plug into a 208 – 240V single-phase supply.   The control panel is optional but highly recommended. However, if not purchased, the user should monitor the temperature not to exceed 1200°C during use.

The control Panel BPAN-O-PLUS when purchased, can be supplied in a UL or cUL rating. This control panel has an SCR, soft start, and two readouts (one for process temperature and one for the over-temperature function).

Robust Radiator for use up to 1200C without caps and 1300C with caps

220V plug-in*
Power: 2kW
Diameter 2″ Length 4″.  Please see the description tab for more details.

GRR High Uniformity Robust Radiators may be used to approximately 1200°C.
For temperatures higher than 1300°C for a Robust Radiator, please click on Robust Radiators and choose the MRCL or RHUL models.

* Plug-in Voltage indicates closest BPAN preference.
The GRR unit temperature, current or power cannot be exceeded in any configuration of use.
Configuration of use changes with end caps, load, flow placement of control thermocouple and insulation.
Please check manual for maximum element temperature that cannot be exceeded.
